Teltonika RUT955 Quick Start Guide

8 Login to device
9 SIM card recommendations
Safety information
Before starting operating the device, please review recommendations and precautions to minimize the possibility of accidents. Safety precautions presented are
supplementary and subject to the local safety regulations. When various operations are executed on the device, the user must fully follow the safety instructions and
recommendations provided with the device.
General
Radio specifications
RF technologies 2G, 3G, 4G, WiFi, GNSS
Max RF power 33 dBm@GSM, 24 dBm@WCDMA, 23 dBm@LTE, 20 dBm@WiFi
Bundled accessories specications*
Power adapter Input: 0.45A@100-240 VAC, Output: 9 VDC, 1A, 4-pin plug
Mobile antenna 698~960/1710~2690 MHz, 50 Ω, VSWR<3, gain** 4 dBi, omnidirectional, SMA male connector
WiFi antenna 2400~2500 MHz, 50Ω, VSWR<2, gain** 3dBi, omnidirectional, RP-SMA male connector
GNSS antenna 1575.42-1602 MHz, 2.2-5 VDC, VSWR<1.5, gain** 28 dB (typ.), RHCP polarization, SMA male connector
* Order code dependant.
** Higher gain antenna can be connected to compensate for cable attenuation when a cable is used. The user is responsible for the compliance with the legal regulations.
RUT955 router must be used in compliance with any and all applicable national and international laws and with any special restrictions regulating the utilization of the
communication module in prescribed applications and environments.
CE Declaration of Conformity
[BG]
Bulgarian
С настоящето, TELTONIKA NETWORKS декларира, че RUT955 е в съответствие със съществените изисквания и другитепри ложими разпоредби на
Директ ива 2014/53/EU
[HR]
Croatian
Ovim TELTONIKA NETWORKS izjavljuje da je ovaj RUT955 u skladu s bitnim zahtjevima i ostalim relevantnim odredbama Direktive 2014/53/EU
[CZ] Czech TELTONIKA NETWORKS tímto prohlašuje, že RUT955 splňuje základní požadavky a všechna příslušná ustanoveni Směrnice 2014/53/EU
[DK] Danish
Undertegnede TELTONIKA NETWORKS erklærer herved, at følgende udstyr RUT955 overholder de væsentlige krav og øvrige relevante krav i direktiv
2014/53/EU
h i bij kl O A O S d h l 9 i i i d iël i d d l b li

Teltonika RUT955 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB 2.0 ports quantity	1
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN (RJ-45) ports	4
4G standard	LTE
2G standards	Edge
3G standards	DC-HSPA+, HSPA+, WCDMA
GSM bands supported	800, 850, 900, 1800, 1900 MHz
Antennas quantity	5
Security algorithms	IPSEC, SNMP, WEP, WPA, WPA2
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power
Housing material	Aluminum
Processor frequency	560 MHz
AC input voltage	100 - 240 V
Power source type	AC, DC
Power consumption (typical)	7 W
Storage temperature (T-T)	-45 - 80 °C
Operating temperature (T-T)	-40 - 75 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	46 mm
Width	106 mm
Height	80 mm
Weight	280 g
