Temco TEF26 - Replacement Parts

10
10007169
305mm [12"]
216mm [8 1/2"] (DISTANCE BETWEEN TWO SOCKETS}
216mm [8 1/2"] (DISTANCE BETWEEN TWO SOCKETS)
1
2
3
4
5
6
8
7
10
11
9
CFM Specialty Home Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and prod-
ucts at any time, without notice.
TEF26/33/36 Electric Fireplace
Ref. Description TEF26 TEF33 TEF36
1. Logset 10006711 10006532 10006587
2. Ember Lava Rock 10006710 10006526 10006588
3. Circuit Board 10006506 10006506 10006506
4. Refractory Right Side 10006601 10006523 10006585
5. Refractory Left Side 10006602 10006524 10006584
6. DC Motor 10001978 10001978 10001978
7. Heater/Fan Assembly 10006538 10006538 10006538
8. Glass Door Assembly 10006551 10006543 10006558
9. Flame Generator Assembly 10003566 10003350 10003350
10. Socket w/Wire Assembly 10006453 10006454 10006454
11. Power Cord 10003095 10003095 10003095
12. Screen Diffuser (not shown) 10006423 10006422 10006576
