0 to 500Ω for current output , 10KΩ minimum for Voltage Output
0.01% for full load change
0.1Second (stable to 99.9%)
22.2mA or 5.55V,11.1V min
0 - 22.2mA (0 - 20mA/4 - 20mA), 0 - 5.55VDC (0 - 5VDC, 1 - 5VDC),0 - 11.1VDC (0 - 10VDC)
Number of Displays (setpoint,
temperature, ect.)
PC Communication Function
Automatic Setup, Calibration and Firmware upgrade
Reverse (Heating) or Direct (Cooling) Action
PID cooling control, Cooling P band 50~300% of PB, Dead band -36.0 ~ 36.0 % of PB
0.1~50.0°C (0.1~90.0°F ) hysteresis control ( P band = 0)
0 - 100.0 % offset adjustment
Fuzzy logic modified Proportional band 0.1 ~ 500.0°C(0.1~900.0°F), Integral time 0 – 3600 Secs, Derivative Time 0 - 360.0 Secs
Cold Start and Warm Start
Auto transfer to manual mode while sensor break or A-D Converter damage
0 to 500.0°C (0 to 900.0°F)/Minute or 0 to 500.0°C (0 to 900.0°F)/Hour Ramp Rate
0,0.2, 0.5, 1, 2, 5, 10, 20, 30, 60 Seconds, Programmable
1 Program with 16 Segments, 2 Programs with 8 Segments each, or 4
Programs with 4 Segments each
Environmental and Physical Specifications
0 to 90 % RH (Non-Condensing)
2000VAC,50/60 Hz for 1 Minute
10 to 55 Hz , 10m/s
2
for 2 Hours
Flame Retardant Polycarbonate
15/16 x 1 7/8 x 3
13/16”
(24*48*92)
1 7/8 x 1 7/8 x
2 3/8”
(48*48*59)
3 3/4 x 1 7/8 x
2 3/8”
(96*48*59)
1 7/8 x 3 3/4 x
2 3/8”
(48*96*59)
2 27/32 x 2
27/32 x 2 3/8”
(72*72*59)
3 3/4 x 3 3/4 x
2 3/8”
(96*96*59)
3 3/4 x 7/8
x
3 11/16”
(96*22.5*8
3)
1 25/32 x 1
25/32” (45*45)
2 11/16 x 2
11/16” (68*68)
