Tempco TEC-9100 User Manual

Page 7 of 12
Chapter 3 Programming
Press for 5 seconds and release to enter the setup menu. Press
to select the desired parameter. The upper display
indicates the parameter symbol, and the lower display indicates
the selected value of the parameter.
3–1 Lockout
There are four security levels that can be selected using the LOCK
parameter.
If NONE is selected for LOCK, then no parameter is locked.
If SET is selected for LOCK, then all setup data are locked.
If USER is selected for LOCK, then all setup data as well as
user data (refer to section 1-5) except the set point are
locked to prevent them from being changed.
If ALL is selected for LOCK, then all parameters are locked to
prevent them from being changed.
3–2 Signal Input
INPT: Selects the sensor type or signal type for signal input.
Range: (thermocouple) J-TC, K-TC, T-TC, E-TC, B-TC,
R-TC, S-TC, N-TC, L-TC
(RTD) PT.DN, PT.JS
(Linear) 4–20mA, 0–20mA, 0–60mV, 0–1VDC,
0–5VDC, 1–5VDC, 0–10VDC
UNIT: Selects the process unit
Range: °C, °F, PU (process unit). If the unit is set for nei-
ther °C nor °F, then it defaults to PU.
DP: Selects the resolution of process value.
Range: (For T/C and RTD) NO.DP, 1-DP
SL = Setpoint Low Stop SH = Setpoint High Stop

Tempco TEC-9100 Specifications

General

Display	Dual 4-digit LED
Mounting	Panel mount
Control Mode	PID
Input Type	Thermocouple, RTD
Output Type	Relay, SSR
Power Supply	24 VAC/VDC
Temperature Range	According to sensor type
Resolution	0.1°C or 0.1°F
