GBS-16 Gasoline Confined Space Fan Parts List
Item # Part number Description
1
100-003 BOLT 5/16-18 X 1 3/4 HEX G5 Z
2 100-044 BOLT 1/4-20 X 1/2 WING Z 3
100-088 BOLT 1/4-20X1/2BUT SHCS
4
100-099 BOLT 10-32 X 5/8 SHCS
5
120-004 WASHER #14 X 5/8 STEEL/NEO
6
120-008 WASHER 5/16 X 7/8 HEAVY F/W
7
120-031 WASHER #10 ALU. BACK UP
8
130-001 NUT 5/16-18 NYLOCK
9
130-002 NUT 10-32 NYLOCK
10
200-013 FUEL LINE 95001-45008-60M HONDA (ORDER 19 INCHES)
11
220-113 GBS CARBURATOR COVER RED
12
220-112 GBS MUFFLER COVER RED
NI 350-025
ENGINE HONDA 118 cm3 GX120
14 500-014 DUCT HOSE ADAPTER 16 SQ 15
580-009 PAD FOOT EBS 16 ZB-1013-MI
16*
600-024 GRILL WITH HARDWARE EBS16
17
600-480K GBS FRAME WELDMENT 16" ( Includes Decals)
18*
600-481K GBS 16 FUEL TANK
19*
600-482K GRILL INNER GBS 16 WITH HARDWARE
20*
705-291 GBS16 IMPELLER KIT
* Denotes item includes necessary hardware for installation NI, Not illustrated
Page 22
