CHAPTER 9
FINAL ASSEMBLY
9-1 INTRODUCTION: Table 9-1 is a listing of all the modules in the RX-340 that can
be replaced in corrective maintenance procedures. Figure 3-1 illustrates where the
modules are located in the chassis. Table 9-2 is a listing of additional small parts which
may need to be replaced if the receiver has been damaged.
TABLE 9-1 RX-340 MODULES
DESCRIPTION TT PART NO.
81772.TCXO
81790.SMD
81807
81817.SMD
81819
81820
81823.SMD
81824
81878
SYNTHESIZER
CONVERTER (I/O)
CPU/DSP
2
ND
MIXER 3
RD
/LO
FRONT PANEL CPU
KEYPAD
1STMIXER
P.S. FILTER
RX PRESELECTOR
9-1
