1-7
Receiver Sensitivity:
Dynamic Range:
Noise Figure (dB) 3rd Order Intercept (dBm)
Mode
Typ Max Typ Min
10 dB PREAMP ON 10 14 20 15
PREAMP OFF 17 19 30 25
15 dB ATTEN 32 34 45 40
VLF Sens.,Typ, .3kHz bandwidth preamp OFF.
16 dB SINAD
>500 kHz -116 dBm (.35 µV)
100 kHz -115 dBm (.4 µV)
50 kHz -114 dBm (.45 µV)
20 kHz -107 dBm (1 µV)
15 kHz -104 dBm (1.4 µV)
10 kHz -94 dBm (4.5 µV)
5 kHz -82 dBm (18 µV)
Spurious Responses: All spurious less than -119 dBm equivalent input- preamp ON.
Control Interface:
Standard: Multi-drop RS-232.
Config: Dipswitch programmable, 300 to 19200 baud, 7 or 8 data bits,
even, odd, or no parity.
Connector: DB-25 female.
