TABLE OF CONTENTS continued
PARAGRAPH PAGE
4. LOCAL OPERATION continued.
4-31 USING THE SCROLL FUNCTION TO PREVIEW THE
CHANNEL MENU
4-16
4-32 USING THE TUNE FUNCTION TO ACCESS
FREQUENCIES FROM THE CHANNEL MENU
4-17
4-33 CLEARING OCCUPIED CHANNELS TO CREATE EMPTY
CHANNELS
4-18
4-34 SCAN MODE PRIMER 4-18
4-35 TO SETUP A PSCAN (PROGRAMMED F
1
→ F
2
)
FREQUENCY SWEEP
4-20
4-36 INITIATING SCAN 4-23
4-37 FREQUENCY LOCKOUTS 4-23
4-38 TO SET UP A MEMORY/SCAN FREQUENCY SWEEP 4-25
4-39 INITIATING MSCAN 4-28
4-40 LOCKING OUT MSCAN CHANNELS 4-29
4-41 PAUSING AND RESTARTING SCANS 4-29
5. DETAILED OPERATING INSTRUCTIONS
5-1 MULTI-DROP NETWORK 5-1
5-2 RECEIVER CONTROL 5-2
5-3 RECEIVER RESPONSE COMMANDS 5-3
5-4 RECEIVER CONTROL COMMANDS 5-3
5-5 RX-340 RECEIVER MEMORY COMMAND SET 5-9
5-6 RX-340 RECEIVER QUERY COMMAND SET 5-9
5-7 RX-340 RECEIVER BITE 5-11
5-8 DSP DATA OUTPUT 5-11
5-9 SCAN OPERATION 5-12
5-10 SECURITY FUNCTIONS 5-14
6. MAINTENANCE INSTRUCTIONS
6-1 INTRODUCTION 6-1
6-2 CLEANING AND LUBRICATION 6-1
6-3 TROUBLESHOOTING 6-1
6-4 INSPECTION 6-1
6-5 PERFORMANCE VERIFICATION TEST FOR MODEL RX-
340
6-1
6-5.1 TEST EQUIPMENT REQUIRED FOR MODEL RX-340 6-1
6-5.2 FUNCTIONAL TESTS FOR MODEL RX-340 6-2
7. PREPARATION FOR SHIPMENT OR STORAGE
7-1 PREPARATION FOR RESHIPMENT 7-1
7-2 PREPARATION FOR STORAGE 7-1
