5-6
COMMAND DESCRIPTION VALID RANGE
Kn PRE-AMP/ATTENUATOR
Allows control of Preamp and Attenuator
‘K1’ Normal - Preamp OFF, attenuator OFF
‘K2’ Preamp on, attenuator OFF
‘K3’ Attenuator on, preamp OFF
1 - 3
Mn AGC OPERATING MODE
Selects the AGC operating mode. ‘F’, ‘M’, ‘S’, and ‘P’ are
displayed in front of AGC setting on front panel. Where ‘n’ is one
of the following:
‘M1’ FastAGC
‘M2’ Medium AGC
‘M3’ Slow AGC
‘M4’ Programmable AGC
Note: The receiver will accept and execute a manual gain ‘A’
command in any of the AGC modes.
1 - 4
PROGRAMMABLE AGC MODE SETTINGS
Note: Receiver accepts new parameters for Programmable AGC at
any time, but uses them only in Programmable mode (M4).
MA Set Attack Rate in dB/mS.
Example: ‘MA0.40’ Program for 0.4 dB/mS
Range:
00.01 to 01.00
MD Program Decay Rate in dB/sec.
Range:
00.01 to 99.99
MH Program Hang Time in seconds.
Range:
00.01 to 99.99
# Dump AGC state and restart AGC process.
