Tenda F3 User Manual

31
your WISP in the Key field.
 Click Close Scan.
 Click OK.
The router will reboot automatically.
After the router reboots, check the WAN status. If it displays Connected, it indicates that you can
access to the Internet now.
If you failed to connect to your WISP, try following steps below one by one to solve the problem:
1. Check the security key (WiFi password), the SSID (wireless network name), channel, seurity
mode, and WPA Algorithms.

Tenda F3 Specifications

General

Color	white
Wi-Fi Speed	300 megabits per second
Band Technology	single
Frequency Band	2.4 ghz
Beamforming	yes
Ethernet Standard	10/100
Ethernet Switch	yes
Wireless Standard	n
Antennas	3
Firewall	none
Data Encryption	yes
Encryption Type	wpa, wpa-psk, wpa2, wpa2-psk
Security Features	wpa algorithm: aes, tkip, tkip&aes; wireless access control: mac address filtering
Ports	rj-45
LAN Ports	3
WAN Ports	1

Weight and Dimensions

Height	1.02 inches
Width	5.02 inches
