Tenda F6 User Manual

40
Prerequisites

The WAN IP address of the router is a public IP address, which is 102.33.66.88.

Computer 1 is assigned a fixed IP address, which is 192.168.0.100 (Refer to IP-MAC
binding function).

The internal port of the web server is 1555. And the external port number to access the
web server is also 1555.
Configuration procedure:
Step 1 Choose Advanced, and move to Port Forwarding to enter the configuration page.
Step 2 Enter Internal IP to the IP address of the web server, which is the IP address of computer
1, 192.168.0.100.
Step 3 Enter Internal Port to the port number of the web service, which is 1555 in this example.
Step 4 Enter External Port, which is 1555 in this example.
Step 5 Set Protocol to Both.
Step 6 Click , and then OK at the bottom of the page.
----End
Verification
Enter Protocol name://WAN port IP address:External port in the address bar of a web browser on a
computer over the internet to access the resources on the web server. In this example, enter
http://102.33.66.88:1555.
To make the port forwarding function always effective, you can use both the port forwarding and
DDNS functions to allow internet users to access the LAN server using a domain name.

Tenda F6 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Product type	Tabletop router
Product color	White
LED indicators	WLAN
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Frequency band	2.4 GHz
Firewall security	Support Oray.com，88ip
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Certification	CCC, CE
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
DSL WAN	No
WAN connection type	RJ-45
Power source type	DC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	211 mm
Width	204 mm
Height	147.5 mm
