Tenda F6 User Manual

42
Assumption
DDNS service provider: oray.com
Domain name: tenda-winnie.imwork.net
Username: tenda-winnie
Password: a1234578
Web server IP address: 192.168.0.110
Internal port number of the web server and the external port number to access the web server:
8080
Network topology
Configure procedure
Step 1 Refer to Port forwarding to configure port forwarding function.
Step 2 Configure DDNS function.
1. Choose Advanced, and move to DDNS to enter the configuration page.
2. Set DDNS to Enable.
3. Set Service Provider to oray.com.
If you do not have a DDNS account, select a service provider and click to go to the
service provider’s website. Register a DDNS account and memorize your user name, password, and
domain name of the account.
Computer 1 (web server)
Ethernet cable
Ethernet cable
Internet
Computer 2

Tenda F6 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Product type	Tabletop router
Product color	White
LED indicators	WLAN
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Frequency band	2.4 GHz
Firewall security	Support Oray.com，88ip
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Certification	CCC, CE
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
DSL WAN	No
WAN connection type	RJ-45
Power source type	DC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	211 mm
Width	204 mm
Height	147.5 mm
