Tenda O1 User Manual

109
7.1.3 Set up a wireless network encrypted using WPA2-PSK
Networking requirement
A factory uses CPEs to set up to set up a wireless network. It requires that the wireless network
has a certain level of security. In this case, WPA2-PSK mode is recommended. See the following
figure.
Network topology
Configuration procedures
Step 1 Start a web browser on the computer connected to the CPE, visit 192.168.2.1 and choose
Wireless > Basic.
Step 2 Change the value of the SSID text box to Factory.
Step 3 Set Security Mode to WPA2-PSK and Encryption Algorithm to AES.
Step 4 Set Key to 87654321.
Step 5 Click Save.
SSID: Factory
Key: 87654321
Router
Switch
Computer
Internet

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
