Tenda O1 User Manual

6
1.2 CCTV surveillance
To ensure the safety of employees and property, a video surveillance system needs to be installed
in a building site.
1.2.1 Solution
Tenda CPE can meet this demand.
O4 is used as an example to illustrate the installation procedures. Procedures for other CPEs are
similar.
1.2.2 Set up the CPEs
At least two CPEs are required for bridging.
Option 1: Automatic bridging (recommended)
 Automatic Bridging is only applicable when the CPEs are in factory settings.
 When performing peer-to-peer bridging, ensure that only two CPEs are powered on nearby.
Otherwise, the peer-to-peer bridging may fail.
 For peer-to-multiple peers bridging, perform peer-to-peer bridging first, and then power on the
rest CPEs within 30 minutes.
 A CPE can bridge to 15 CPEs at most.
Scenario 1: Peer-to-peer bridging
Step 1 Place the two CPEs next to each other, see the following figure.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
