Tenda O1 User Manual

184
9.4 System log
To access the page, choose Tools > System Log. The maximum of 300 items can be saved. After the
total log items exceed the maximum number, the previous logs will be cleared.
The logs of the device record various events that occur and the operations that users perform
after the device starts. In case of a system fault, you can refer to the logs during troubleshooting.
To ensure that the logs are recorded correctly, verify the system time of the device. You can
correct the system time of the device by choosing Tools > Date & Time.
To view the latest logs of the device, click Refresh. To clear the existing logs, click Clear.
 When the device reboots, the previous logs are lost.
 The device reboots when one of the following situations occurs: the device is powered on after a
power failure, the VLAN function is configured, the firmware is upgraded, the configuration of the
device is backed up or restored or the factory settings are restored.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
