Tenda O1 User Manual

71
Parameters description
Name
Description
Working modes
It specifies the working mode of this device.
Router mode: In this mode, the PoE/LAN port works as the WAN port and is used to
connect to a modem for internet access.
Internet Connection
Type
The device in Router mode supports three internet connection types:

DHCP (Dynamic IP): The device obtains the IP address and other parameters from the
DHCP server of upstream device for internet access.

Static IP Address: The device accesses the internet using the IP address, subnet mask,
default gateway and DNS server IP addresses provided by your ISP.

PPPoE: The device accesses the internet using the PPPoE user name and password
provided by the ISP.
SSID
It specifies the wireless network name of the device.
Channel
It specifies the channel that the WiFi network operates.
Security Mode
It specifies the security mode of the WiFi network of the device. It includes None,
WPA-PSK, WPA2-PSK, and Mixed WPA/WPA2-PSK.
Clicking the hyperlink navigates you to the elaborated description of the corresponding
security mode.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
