Tenda W311M User Manual

Wireless Network Adapter Users’ Guide
Chapter 2 Installation Guide
This chapter will assist you in installing network
adapter software packet by using the included CD. The
software packet program has integrated driver and
configuration software. So when you are installing driver
the configuration software will be automatically installed
as well.
Windows XP is used as an example to explain the
installation steps. Installation in other operation systems,
please refer to their corresponding prompts.
1. Please insert the Wireless USB Adapter into the USB
port of your computer.
2. System will pop up a “Found New Hardware”dialogue
box. We recommend you to select “Cancel”and use the
attached quick installation CD to easily install driver and
configuration software.
-6-

Tenda W311M Specifications

General

Interface	WLAN
Connectivity technology	Wireless
Chipset	-
Internal	No
Certification	FCC, CE, WEEE
Product color	Black, White
LED indicators	Activity, Link
Wi-Fi	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	150 Mbit/s
Gain	2 dBi
Sustainability certificates	RoHS
Minimum RAM	64 MB
Minimum processor	733MHz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	38.4 mm
Width	17.2 mm
Height	7.9 mm
