Tenda W311M User Manual

Wireless Network Adapter Users’ Guide
-41-
802.11a An extension to 802.11 WLAN standards
that provides up to 54 Mbps transmission
in the 5 GHz UNI radio band.
802.11b An extension to 802.11 WLAN standard
that provides up to 11 Mbps transmission
in the 2.4 GHz ISM radio band. 802.11b
uses DSSS modulation.
802.11g An extension to 802.11 WLAN standard
that provides up to 54 Mbps transmission
in the 2.4 GHz ISM radio band. 802.11b
uses OFDM modulation and is backwards
compatible with 802.11b.
WEP Wired Equivalent Privacy. A security
protocol for WLANs defined in the IEEE
802.11 standard.
WPA Wireless Protected Access ， adopts
rotating keys.
ICS Microsoft Internet Connection Sharing
enables multi-computer to share access to
Internet via one PC.

Tenda W311M Specifications

General

Interface	WLAN
Connectivity technology	Wireless
Chipset	-
Internal	No
Certification	FCC, CE, WEEE
Product color	Black, White
LED indicators	Activity, Link
Wi-Fi	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	150 Mbit/s
Gain	2 dBi
Sustainability certificates	RoHS
Minimum RAM	64 MB
Minimum processor	733MHz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	38.4 mm
Width	17.2 mm
Height	7.9 mm
