3
IMPORTANT SAFETY INFORMATION
Please read these instructions carefully before use and retain for future
reference.
• When using electrical appliances basic safety precautions should always be
followed.
• Use the meter only as specied in this manual, or the protection provided may be
impaired.
• Do not operate the meter or use test leads if they appear damaged, or if the meter
is not operating properly. Check before each use.
• There are no user-serviceable parts in this product. Refer servicing to qualied
personnel.
• Do not use the clamp meter in a circuit with voltage higher than 600V or frequency
higher than 400Hz.
• Be cautious when working in an environment with exposed conductors. Contact
with conductors may result in electric shock.
• Use caution with voltages above 60V DC, 30V AC rms or 42V AC (peak value).
These voltages pose a shock hazard.
• Before removing the battery cover, remove the clamp meter from all energized
circuits and disconnect the lead.
• Replace the batteries as soon as the low battery indicator appears on the display.
• Fit a full set of batteries at one time.
• Remove dead batteries from the meter or if it is not going to be used for a long
time.
• Never mix old and new batteries together, or different types of batteries.
• Never dispose of batteries in a re, or attempt to recharge ordinary batteries.
TECHNICAL SPECIFICATION
Max. voltage between input terminal
and earthing
600V
Max. overload protection for clamp
head terminals
100A
Max. display
2000 counts, update 2-3 times per
second
Over range display Displays “OL”
Diode (approx) 3.2V
Range Automatic
Polarity Automatic
Work temperature 0°C ~ 40°C
Relative humidity 0°C ~ 30°C: 75%, 30°C ~ 40°C: 50%
Storage temperature -10°C ~ 50°C
