Tenma 72-7765A - AC CURRENT MEASUREMENT; RESISTANCE, DIODE, AND CONTINUITY MEASUREMENT; Resistance Measurement Specs; Diode and Continuity Measurement Specs

5
AC CURRENT
Range Resolution Accuracy Overload protection
400μA 0.1μA
± (1.5%+5)
400mA/250V fast type fuse
Φ5x20mm
400mA/250V fast type fuse
Φ5x20mm
4000μA 1μA
40mA 10μA
± (2%+5)
400mA 100μA
4A 1mA
± (2.5%+5) 10A/600V fast type fuse Φ6x25mm
10A 10mA
DIODE AND CONTINUITY MEASUREMENT
Range Resolution Accuracy Overload protection
1mV
Displaying approximate
forward voltage drop
250V DC and AC
0.1Ω
(72-7765A)
Beeping if impedance <100Ω
1Ω Beeping if resistance <70Ω
RESISTANCE
Model Range Resolution Accuracy
Overload
protection
72-7765A
400Ω 0.1Ω ± (1.2%+2)
250V DC and AC
4kΩ 1Ω ± (1%+2)
40kΩ 10Ω ± (1%+2)
400kΩ 100Ω ± (1%+2)
4MΩ 1kΩ ± (1.2%+2)
40MΩ 10kΩ ± (1.5%+5)
72-10420A
72-7770A
200Ω 0.1Ω ± (0.8%+5)
2000Ω 1Ω ± (0.8%+2)
20kΩ 10Ω ± (0.8%+2)
200kΩ 100Ω ± (0.8%+2)
20MΩ 10kΩ ± (1%+5)
200MΩ 100kΩ
± (5%[reading-10]+10)
(72-7770A)
