Tenma 72-7780 - General Specifications; Specifications; Structure


Diode

AC/DC
 Warning

Grounding

Currentclamp

Doubleinsulation

ComplywithEuropeanUnionDirectives
V. Generalspecifications
1) Maxvoltagebetweeninputterminalsandearthgrounding:SeeTechnical
Specifications
2) FuseType:
10AJack:F10AH600VFuse(Φ6x25)mm
mA/μAJack:F600mAH600VFuse(Φ6x32)mm
3) MaxDisplayValue:
Capacitancemeasurement:9999
Frequencymeasurement:9999
Othermeasurement:6000
DutyRatio：1~99.9%
Diode:3.2V
Others:
1) Range:Auto/Manual
2) Polarity:Auto
3) Displayupdates2~3timesforeverysecond.OverrangeIndicator:“OL”
4) Operatingtemperature:0˚C~40˚C(32˚F~104˚F)
Storagetemperature:‐10˚C~50˚C(14˚F~122˚F)
Relativehumidity:≤75%at0˚C~30˚C;≤50%at30˚C~40˚C
5) Operatingaltitude:0~2000m
6) Batterytype:AAR6P1.5V×2
7) Lowpowerindicator:
8) Dimension:175mm×80mm×48.5mm
9) Weight:350g(batteriesincluded)
10) Electromagneticcompatibility:
 RF≤1V/m,overallaccuracy=specifiedaccuracy+5%ofrange.
 RF>1V/m,nospecifiedcalculation.
VI. Structure(seefigure1) 
1/Protectivecase
2/Displayscreen
3/4/7Functionalbuttons
5/Functionaldial
6/Inputjacks
VII. Display
