Tenma 72-7780 - Controls and Operation; Functional Dial and Button Operations


Symbol Indication

Datahold
━
Negativevalue
AC/DC ACorDCmeasurement
MAX/MIN Maximumorminimumreading

Lowpower
AutoRange Autorangeselection

Diodemeasurement

Continuitymeasurement

Relativemeasurement
Ω、kΩ、MΩ
Unitofresistance
Hz、kHz、MHz
Unitoffrequency
% Unitofdutyratio
mV、V
Unitofvoltage
μA、mA、A
Unitofcurrent
nF、μF、mF
Unitofcapacitance
˚
C Celsiusdegree
˚
F Fahrenheitdegree
NCV Non‐contactvoltage

Autoshutdown

Currentclamp
VIII. Functionaldialandbuttons
Position Note
V 、V 、mV 
AC/DCvoltage
Ω Resistance

Diode

Continuity

Capacitance
Hz Frequency
% Dutyratio
˚C/˚F Temperature
μA mA A  AC/DCcurrent
60A  AC/DCcurrentclamp
