Safety Symbols 2
The instrument has double insulation or reinforced insulation.
ACV
AC Voltage
Ground
Comply with European Union standards
3. Technical Specication
Accuracy ±(a% reading+digits); calibration per year.
Ambient Temperature (23±5)°C
Environmental Humidity 45% to 75%
Insulation Resistance Measurement
Rated Voltage 100V 250V 500V 1000V
Test Range
0.00MΩ to 5.5G (When it is about less than 4MΩ, buzzer outputs alarming
sounds). Notes: (100V) 0.00MΩ to 100MΩ
Opened Voltage DC100V ±10% DC250V ±10% DC500V ±10% DC1000V ±10%
Rated Test
Current
When load is
100kΩ, the rated
testing current is
0.9mA~1.1mA
When load is
250kΩ, the rated
testing current is
0.9mA~1.1mA
When load is
500kΩ, the rated
testing current is
0.9mA~1.1mA
When load is
1MΩ, the rated
testing current is
0.9mA~1.1mA
Shorted Current About less than 1.8mA
Accuracy 0.00MΩ to 99MΩ: ±(3% + 5 digits); 100MΩ to 5.5GΩ: ±(5% + 5 digits)
Voltage Measurement
AC Voltage
Test Range 30V~750V (50Hz/60Hz)
Resolution 1V
Accuracy ±(2% + 3 digits)
• Display: LCD, 1999 count
• Low Battery Indication: “ ”
• Overload Indication: “>5.5GΩ” for insulation resistance measurement; “OL V” for voltage measurement
• Autoranging
• Discharge voltage automatically
• Backlight, suitable in dark site
• Red warning light (warning light is on when high voltage outputs)
• Working conditions: 0°C to +35°C; relative humidity is 75% or less; altitude: 2000m
• Storage conditions: -20°C to +60°C / relative humidity is 80% or less
• Dimensions: 150mm (L) × 100mm (W) × 71mm (D)
• Power supply: alkaline batteries, 1.5V (5#) × 6
• Weight: 0.5kg (with battery)
• Accessories: test leads, instruction manual, carrying case, galas
