TM-191
6 Specifications
Display: 3-1/2 digits LCD, maximum reading 1999.
Range: 200/2000 mG,20/200µT.
Resolution: 0.1/1 mG or 0.01/0.1 µT.
Frequency response: 30Hz to 300Hz.
Sensor: Single Axis
Accuracy: ±(2.5%+6dgt) at 50Hz/60Hz.
Over load: LCD display “OL”.
Sample rate: 2.5 times per second.
Battery: 9V NEDA 1604, IEC 6F22 or JIS 006P.
Battery life: Approximate 100 hours.
Operating temperature & humidity: 5℃to 40℃,below
80% RH.
Storage temperature & humidity: -10℃ to 60℃, below
70%.
Weight: About 170g.
Dimensions: 130(L)*56(W)*38(H)mm.
Accessories: User’s manual, 9V battery, Carrying case.
7 Battery replacement
WARNING
If the symbol “
” appears on the LCD, please
replace the battery immediately
Turn off the instrument.
Remove the battery cover
Replace the battery.
Install the battery cover.
EN-4
