ACX-1 Series Instrument www.tensitron.com pg. 7
• Add-On Options
Instruments can be configured with either of these options, but not both:
o - A Analog Output option
Data output at 40 Hz.
0-5 VDC or 4-20 mA with Software-definable ending sequences.
Provided with 10’ cable.
o - E RS-232 Serial Output option
Select data sampling rate from 1, 2 or 5 Hz.
Provided with 10’ cable to Interface with your receiving device.
• Features of all Instruments
o Color graphic display:
▪ Large and easy to read, with adjustable backlighting.
▪ Shows Tension, Battery Charge Level, and Cable Size Selected.
▪ Includes user-definable tension set points.
o Store Function: Store and display up to five separate tension readings plus the
minimum/maximum and average value of these stored readings.
o Data Statistics: Monitor your process by viewing count, average,
minimum/maximum, and standard deviation values of your logged data.
o Selectable Tension Units: Choose to display tension in Lb, Kg or daN.
o Up to ten calibrations can be programmed into the instrument. (Password-
protected to provide due diligence against unauthorized changes.)
o Adjustable LCD refresh rates allow for stable digital readings.
o Automatic shutoff after several minutes of non-use.
o All models are typically available from stock.
o All models are factory calibrated and ready for use.
o All calibration values are traceable to National Standards.
o Calibration certificate is included.
o Continuous operation while connected to power supply.
o Durable, lightweight carrying case with protective foam inserts included. (See
Figure 2)
o Cable diameter gauge included, to easily and accurately measure cable size.
(See Figure 3)
