Calibration
28 V-04/2018
Step 8
If you wish to operate the sensor unit with the base plate in a different position,
the calibration process must be continued.
The sequence of the four possible positions is defined as follows (when
viewing the XLR plug from the sensor unit):
Orientation Display text
I. Base plate down (factory calibration) Mpl Down
1
II. Base plate up Mpl Up
III. Base plate left Mpl Left
IV. Base plate right Mpl Right
Notice
For better clarity about which orientation (I.-IV.) is currently
being calibrated, the display text in the table is displayed briefly.
Notice
Note on step 3: Since the system is already in calibration mode,
it is not necessary to press the “Power” button. Calibration
starts right away with the calibration of position “A” when the
“CAL” button is pressed.
If steps 2 to 6 are carried out correctly with the changed orientation of the base
plate without the text “Sens pos incorrect” appearing on the display, calibration
of the orientation is completed with the display text “Calb Data stored”.
Now the sensor unit can be operated with the base plate either down or up. If
these positions are sufficient, you can exit calibration mode by pressing the
“Power” button to power off the unit.
If the side positions are also desired, steps 2 to 6 must be repeated with the
base plate first to the left (when viewing the XLR plug on the sensor unit). For
orientation with the base plate to the right (when viewing the XLR plug on the
sensor unit), calibration steps 2 to 6 must be repeated again.
Now the sensor unit can be used in all four positions.
1
Mpl: Mounting plate
