Teradek Bolt 6 LT - Tools; Advanced System Settings

Video OSD Settings (RX Only)
- Choose when to display the OSD.
◦
Never show
◦
Show when operating
◦
Show when no video
◦
Always show
Display Settings
- Use the Display Settings to control the OLED display operation. By
default, the OLED display will invert every 30 minutes.
Signal Quality Graph (RX Only) -
The Signal Quality Graph indicates the quality and
reliability of the signal being received according to the amount of interference that is
present between the RX and TX. Signal Quality is represented in percentages:
◦
Figures below 30% indicate
poor
signal quality
◦
Figures between 30% and 45% indicate
fair
signal quality
◦
Figures above 45% indicate
good
signal quality
Spectrum Analyzer (RX Only)
- The built-in Spectrum Analyzer provides a visual
indication of channel noise and saturation across the entire available frequency range.
Move the Menu joystick left and right to select a frequency. Frequencies are
represented by bars; the higher the bar, the more congested that frequency is.
Test Pattern (RX Only)
- This menu allows you to select a video resolution format to
output a test pattern over HDMI or SDI. Select a specific output resolution from the
resolutions list.
Lock Keypad -
The Lock Keypad feature prevents the menu joystick from being used
to avoid any accidental or unauthorized configurations. There are two ways to lock the
keypad:
•
Navigate to
Advanced Setting
s
via the front panel and select
Lock Keypad
.
Tools
Advanced/System Settings
