Teradek Sony Bolt - Page 2

PHYSICAL PROPERTIES
A: RP-SMA connectors
B: Mini USB port
C: Captive screw holes
D: Power button (not shown)
E: Camera mount connector
F: Reset button
G: Power status LED
H: Video status LED
I: Link status LED
J: Fault/Error LED
K: Power input
L: Power switch
M: 3G-SDI outputs
N: NATO rail mount
O: Menu joystick
P: OLED display
Q: HDMI output
I
C
D
I
Bolt 1000/3000 XT - RX
L
A
Q
B
O
J
M
Sony Bolt - TX
C
C
C
B
G
F
K
A
E
H
N
P
