2. Mechanical Design
Figure 2: Top view
1) USB cable with type A plug connector
2) Round vehicle key tray
3) Status LED indicating operating mode(s)
4) Key LED indicating recognition/upload status or device upgrade status
Figure 3: Rear view
1) Grommet for USB cable
2) Rubber plug
2
1
4
3
1
2
