3. Status LED Overview
Status LED (left LED):
Off
Solid
white
Fast blinking
white
Slow blinking
white
No USB
connection to
PC.
USB cable is not
plugged in.
USB connection is OK.
Communication with
ITOOLS-USBTrayApp
established successfully.
USB connection is OK.
Communication with
ITOOLS-USBTrayApp could
not be established.
USB connection is OK.
VIN mode is active.
Key LED (right LED):
Off
Slow blinking
green
Solid
green
Rapid blinking
yellow
No key detected.
Key data uploading.
Key data successfully
uploaded.
Device is in upgrade
mode. Device is
receiving new
firmware.
4. Configuring Desktop KeyReader Plus
The ITOOLS-USBTrayApp software includes all drivers and configuration settings.
Please follow the instructions in the ITOOLS-USBTrayApp manual.
ITOOLS-USBTrayApp is a BMW application built for the BMW ISPI Next environment.
The software distribution, registration and documentation are in compliance with established ISPI
Next standards.
