3. Bin lift operation
37751
12-2014
3.4
Loading bags and/or bulky waste
ã Terberg Machines B.V., IJsselstein, The Netherlands
All rights reserved. No part of this book may be reproduced, stored in database or retrieval system, or published, in any form or in any
way, electronically, mechanically, by print, photoprint, microfilm or any other means without prior written permission from the publisher.
To make it easier to throw in bags and/or bulky
waste, you can lower the throw-in height of the bin
lift
1) Put the bin lift in the lower position before
opening the hopper plate.
2) Hopper plate (06)
Unlock the hopper plate, press down handle A
on the L/H side. Simultaneously, rotate the hop-
per plate all the way down.
Throw in long items sideways.
Do not use the bin lift as a breaking edge.
Incorrect use may damage the bin lift.
Do not forget to raise the hopper plate again
before collecting bins.
