Operations Manual United Kingdom 1-October-2013
TA9 & 10 Tier 4 Page 13
Appendices
1 Switch - Hazard Warning Lights Colour Codes
2 Switch - Direction Indicators RD - Red
3 Headlamp Assembly - RH WH - White
4 Headlamp Assembly - LH YE - Yellow
5 Flasher Unit GN - Green
6 Switch - Brake Pressure BU - Blue
7 Switch - Lighting GY - Grey
8 Registration Plate Lights OR - Orange
9 Rear Light Assembly - RH BK - Black
10 Rear Light Assembly - LH PU - Purple
11 Circuit Breaker PK - Pink
12 Ignition Feed on Dash Harness BN - Brown
