LED Flashing Battery State Mode or Event
Red For 2 seconds Normal
Low Battery
Charging
● Rider A connected
● Set VOX to disabled
Red Remains on Charging ● Off
Red/Blue Alternating fast Normal
Low Battery
Charging
● Pairing Mobile 1
Red/Blue Alternating slow Normal
Low Battery
● Pairing GPS 1
Red/Green Alternating fast Normal
Low Battery
Charging
● Pairing Mobile 2
Red/Green Alternating slow Normal,
Low Battery
● Pairing GPS 2
Yellow Fast (repeating) Normal
Low Battery
Charging
● Incoming/outgoing connection
Yellow For 2 seconds Normal
Low Battery
Charging
● Intercom call attempted without
microphone or audio kit connected.
© 2018 Terrano Systems
All rights reserved. Terrano, the Terrano logo and other Terrano marks are owned by Terrano and may be
registered. All other trademarks are the property of their respective owners. Terrano Systems assumes no
responsibility for any errors that may appear in this document. Information contained herein is subject to change
without notice.
24
