APPENDIX A. TERRANO XT MODES AND EVENTS -
LEDINDICATIONS
Your TERRANO XT operates in various modes. Each mode consists of a group of features currently available for
your use. For example, when TERRANO XT plays music, it will be in music playing mode, enabling features
related to playing music such as skipping to the next and previous tracks.
"Events" are considered to occur whenever you operate a feature and when TERRANO XT's responds. For
example, turning on music is an "event".
TERRANO XT's current mode is indicated by the unit LEDs. You also hear voice announcements on your unit for
mode changes and events.
The following table shows LEDindications for modes and events according to the current battery state.
LED Flashing Battery State Mode or Event
Blue For 2 seconds Normal Rider B connected
Set VOX to enabled
Blue Fast (3 times) Normal
Low Battery
Charging
Power on
Blue Fast (repeating fast) Normal,
Low Battery
Charging
Pairing intercom rider B
Blue Slow (repeating every 3 seconds) Normal Standby
Blue Slow twice (repeating slowly every 3
seconds)
Normal Incoming/outgoing call (intercom or
mobile)
Audio active (intercom, FM, A2DP, GPS,
Feature/Settings menu)
Off Off Normal
Low Battery
Off
Purple Fast (repeating fast) Normal
Low Battery
Charging
Pairing intercom rider C
Purple For 2 seconds Normal
Low Battery
Charging
Mobile pairing successful
Mobile connected
Rider C connected
GPS pairing successful/connected
Purple Slow (5 times) Normal
Low Battery
Reset pairing
Purple/Red Purple twice slowly and red on Charging Incoming/outgoing call (intercom or
mobile)
Audio active (intercom, FM, A2DP, GPS,
Feature/Settings menu)
Purple/Red Slow purple and red (repeating) Charging Standby
Red Slow twice (repeating slowly every 3
seconds)
Low Battery Incoming/outgoing call (intercom
ormobile)
Audio active (intercom, FM, A2DP, GPS,
Feature/Settings menu)
Red Fast (repeating slowly every 3 seconds) Low Battery Standby
Red Fast (repeating fast) Normal
Low Battery
Charging
Pairing intercom rider A
Red Fast (3 times) Normal
Low Battery
Charging
Power off
23
