TES APM-15 - 2.3.2 Timing and EDID Data

19
2.3.2 Timing Table Chart
Mode
NO
Resolution
H-Freq. (KHz)
Band Width
(MHz)
Polarity
H
V
1
102
720x400 70Hz
31.47
28.322
－
＋
2
103
VGA 640x480 60Hz
31.47
25.175
－
－
3
182
MAC 640x480 66Hz
35
30.24
－
－
4
173
640x480 72Hz
37.86
31.5
－
－
5
109
640X480 75Hz
37.5
31.5
－
－
6
104
800x600 56Hz
35.16
36
＋
＋
7
116
800x600 60Hz
37.88
40
＋
＋
8
110
800x600 72Hz
48.077
50
＋
＋
9
117
800x600 75Hz
46.875
49.5
＋
＋
10
108
832x624 (74.55Hz)
49.722
57.28
－
－
11
118
1024x768 (60.0 Hz)
48.363
65
－
－
12
157
1024x768 (70.0 Hz)
56.476
75
－
－
13
141
1024x768 (75.0 Hz)
60.02
78.75
＋
＋
Note: If input H-display > 1024 pixel or V-display > 768 lines or V-Sync >76Hz, then
OSD shall display warning out of range.
2.3.3 EDID Data
DP/HDMI
The monitor assembly shall provide a display communications channel that
conforms to VESA DDC2B hardware requirements. This configuration shall contain
the 256-byte EDID file as specified by VESA EDID Standard.
VGA
The monitor assembly shall provide a display communications channel that
conforms to VESA DDC2B hardware requirements. This configuration shall contain
the 128-byte EDID file as specified by VESA EDID Standar
