15
The CAL factor is often used as a means of entering the
sensitivity of the field sensor in terms of its frequency
response in order to improve measurement accuracy.
Frequency-dependent sensor calibration factors are provided
for this application. In many cases, the measurement
accuracy will be sufficient even if the frequency response of
sensor calibration factor is ignored. CAL can be set to 1.00 in
such cases.
E-Field typically calibration data:
Frequency CAL
10MHz 17.04
50MHz 2.13
100MHz 1.37
200MHz 1.19
300MHz 0.69
433MHz 0.78
500MHz 1.38
600MHz 2.12
700MHz 1.66
800MHz 1.40
900MHz 1.40
1.8GHz 2.06
2.4GHz 0.66
3.5GHz 1.05
5.4GHz 2.20
8.0GHz 3.16
