Your Microwave Oven and Its Components
Turntable
Grill Element
Oven Air Vent
Control
Panel
Turntable Rotor
Turntable
Support Ring
Viewing Window
Door Locking
Assembly
Grilling Plate*
*Safety Handle not illustrated
Ventilation Slots
Open the oven door. In the oven compartment you should find
Introduction
the turntable and rotating support ring, the metal non-stick
Please make sure you read all the instructions and the safety
grilling plate and a safety handle. Unpack all these items.
notes carefully and that you familiarise yourself with the features
Check the oven carefully, especially the door, door seals and the
and operation of your oven before use.
locking mechanism. If any items are missing or damaged, contact
your nearest Tesco store for assistance.
Unpacking the Microwave Oven
If possible retain the packaging. If you dispose of the packaging,
Remove the polystyrene top packing pieces and lift out the oven.
do so having regard to recycling provisions in your area.
Unpack the oven completely removing all the protective tape.
Preliminaries
Place your microwave oven on a flat, level stable work surface $
away from sources of cold, heat and damp.
$
For
$
$
$
Installing the Turntable
Open the oven door.
Check that the rotor is on the motor drive spindle. If not, you
will need to attach it. There is a flat
good ventilation, the rear of the oven should have a clearance
machined on the motor spindle to
of at least 10 cm from the wall, the free distance above the top
hold the rotor secure while the oven
should be at least 20 cm and there should be a gap of at least 5cm
is operating. Rotate the rotor
at both sides.
slightly back and forth until it drops
securely into place over the spindle.
Place the Turntable Support Ring in the oven
Lower the turntable onto the Rotor. There is a recess in the
turntable to lock securely on the rotor.
You must always operate your microwave oven with the
turntable assembly properly in place.
The oven should be plugged directly into the wall socket and not
via an adaptor or any other power sharing device.
5cm
20cm
5cm
10cm
Page 4
START
QUICK START
/
POWER
CONVECTION
GRILL/
MICRO+GRILL
MICRO+
CONVECTION
WEIGHT/CLOCK
TIME
MENU
STOP/CANCEL
The grilling plate
should be used for
grilling only.
Do not use for any
process involving
convection or
microwave cooking.
