TESCO EQUIPMENT LLC
ML50-20 MAINTENANCE LIFT
Figure 1
CONTROL STATION LOCATION
UPPER FIXED AND PENDANT
CONTROL STATIONS
LOWER CONTROL
STATION
DASH MOUNTED
INDICATORS
STABILIZER
CONTROL
STATION
ELECTRICAL PANEL BOX
HYDRAULIC
ENCLOSURE/TANK
MANUAL
OVERRIDE VALVES
Jan. 14
