TESCO EQUIPMENT LLC
ML50-20 MAINTENANCE LIFT
C. Hi-Lift Single Acting Cylinder
• Cylinder Stages 3
• Cylinder Quantity 2
• Stroke 110 in. (2794 mm)
• Fluid Capacity Retracted 3.5 US gal (13.25 l)
• Fluid Capacity Extended 4.8 US gal (18 l)
D. Double Acting Stabilizer Cylinders
• Cylinder Bore Diameter 2.5 in. (63.5 mm)
• Stroke 16 in (406.4 mm)
• Fluid Capacity Retracted
80 in
3
(1.31 l)
• Fluid Capacity Extended
80 in
3
(1.31 l)
E. Hydraulic System
• Hydraulic Pump Gear Type
• Pump Flow Rating at 1200 RPM’s 18.5 gpm (70L/m)
F. Electrical System
• Servo Control Valve Solenoids 12VDC negative ground
• Master Control Valve Solenoid 12VDC negative ground
• Circuit Solenoid Switch & Relays 12VDC negative ground
• Electrical Circuit Protection Thermal circuit breakers
