WARNING: To minimize the risk of
severe injury or death in the event of a
collision, ensure that head supports
are positioned correctly before sitting
in, or operating, Model 3.
WARNING: When installing a seat belt
retained child safety seat in the center
seating position in the second row,
you must lower the associated head
support (described next).
Raising/Lowering the Rear Center Head
Support
To raise the head support, lift it until you hear
it click into place. Push down on the head
support to ensure that it is secure.
To lower the head support, press and hold the
button on the outer base of the right post
and press the head support down.
Removing/Installing a Head Support
To remove the head support:
1. Raise the head support as described
above.
2. Press and hold the button on the outer
base of the right post.
3. Insert a short, flat object (such as a small
flat-head screwdriver) into the opening
on the inside base of the left post and pull
the head support upward.
To re-install the head support:
1.
With the front of the head support facing
forward, insert both posts into the
corresponding holes on the seat back.
2.
Press down on the head support until it
clicks into place.
3.
Pull up on the head support to ensure
that it is secure.
WARNING:
Ensure that the head
support is correctly installed
before seating an occupant.
Failure to do so increases the risk
of injury or death if a collision
occurs.
Seat Heaters
The front and rear seats contain heating pads
that operate at three levels from 3 (highest)
to 1 (lowest).
To operate the seat heaters, see
Climate Controls on page 146.
WARNING:
To avoid burns resulting
from prolonged use, individuals who
have peripheral neuropathy, or whose
capacity to feel pain is limited because
of diabetes, age, neurological injury, or
some other condition, should exercise
caution when using the climate control
system and seat heaters.
Front and Rear Seats
28 MODEL 3 Owner's Manual
