Testec TT-SI 9002 - Specifications

14
9. Specifications
TT-SI 9001 TT-SI 9002
Bandwidth DC to 25MHz (-3dB) DC to 25MHz (-3dB)
Attenuation Ratio 1:10 / 1:100 1:20 / 1:200
DC-Accuracy ±2% ±2%
Rise Time 14ns 14ns
Input Impedance
4MΩ // 5,5pF each side to ground 4MΩ // 5,5pF each side to ground
Input Voltage
- Differential Range
1:10 ±70V (DC+peak AC) or 70Vrms
1:100 ±700V (DC+peak AC)
or 700Vrms
1:20 ±140V (DC+peak AC) or 140Vrms
1:200 ±1400V (DC+peak AC)
or 1000Vrms
Input Voltage
- Common Mode Range
1:10 and 1:100
±700V (DC+peak AC) or 700Vrms
1:20 and 1:200
±1400V (DC+peak AC)
or 1000Vrms
Input Voltage
- Absolute Max.
(Differential or Common)
1:10 and 1:100
±1400V (DC+peak AC) or 1000Vrms
1:20 and 1:200
±1400V (DC+peak AC)
or 1000Vrms
Measurement Category CAT III CAT III
Output Voltage
- Swing
±7V (into 50kΩ load) ±7V (into 50kΩ load)
Output Voltage
- Offset (typical)
<±5mV <±5mV
Output Voltage
- Noise (typical)
0,7mVrms 0,7mVrms
Source Impedance
(typical)
50Ω (for using 1MΩ input system
oscilloscope)
50Ω (for using 1MΩ input system
oscilloscope)
CMRR (typical) -86dB @50Hz, -66dB @20kHZ -80dB @50Hz, -60dB @20kHz
Ambient Operating
Temperature
-10°C to 40°C -10°C to 40°C
Ambient Storage
Temperature
-30°C to 70°C -30°C to 70°C
Ambient Operating
Humidity
25% to 85% RH 25% to 85% RH
Ambient Storage
Humidity
25% to 85% RH 25% to 85% RH
Power Requirements
- Standard
4 x AA Cells 4 x AA Cells
Power Requirements
- Optional
Power lead or Mains Adapter
(6VDC/60mA or regulated
9VDC/40mA)
Power lead or Mains Adapter
(6VDC/60mA or regulated 9VDC/40mA)
Length of BNC Cable
95cm 95cm
Length of Input Leads
45cm 45cm
Weight 400g (probe and PVC jacket) 400g (probe and PVC jacket)
Dimensions (LxWxH) 170mm x 63mm x 21mm 170mm x 63mm x 21mm
