TESTO 176 User Manual

3 Specifications
40
testo 176 H2 (0572 1766)
Feature
Values
Measurement
parameter
Temperature (°C/°F) and humidity (%rF,
%RH, °Ctd, g/m³, WB)
Sensor type 2 capacitive humidity sensors external
Measurement range
0 to 100 %rF (non-dewing)
-20 to +70°C
-40 to +70°Ctd
Instrument
accuracy
± 0.2°C (-20 bis +70°C) ± 1 digit
± 0.4°C (remaining measurement range) ± 1
digit
The accuracy for humidity measurements
results from the accuracy of the connected
sensor.
Resolution 0.1 °C, 0.1 %rF
Operating
temperature
-20 ... +70°C
Storage
temperature
-40 ... +85°C
Battery type 1x lithium (TL-5903)
Service life 8 years (15 min. measuring cycle, +25 °C)
Degree of
protection
IP65
Dimensions in mm
(LxWxH)
103 x 63 x 33 mm
Weight
approx. 430 g
Measuring cycle 1s – 24h (freely selectable, for online
measurement 2s – 24h))
Interface Mini-USB, SD card slot
Memory capacity 2 million readings
EC Directive
2014/30/EC
Pos: 25 /T D/ Lei stung s besc hrei bung /T ech nisc he D at en/t est o 17 6 P 1 @ 6 \mod_1278341642475_79.docx @ 63489 @ 5 @ 1
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

TESTO 176 Specifications

General

Type	Temperature and Humidity Data Logger
Resolution Temperature	0.1 °C
Resolution Humidity	0.1 %RH
Battery Life	Up to 8 years
Interface	USB
Dimensions	103 x 63 x 33 mm
Protection Class	IP65
Temperature Range	-20 to +70 °C
Humidity Range	0 to 100 %RH
Accuracy Temperature	±0.2 °C
Memory	2 million readings
Channels	1 (Temperature and Humidity)
