6 Using the product
38
Pixel mark | New mark
Up to 3 measuring point marks (crosshairs with measurement
values displayed) can be shown and freely positioned.
Task Actions/description
Insert new mark.
> | .
or
>
| | Measurement | Pixel
mark | New mark.
Move crosshairs.
> Touch and drag crosshairs.
Joystick operation:
1. Select crosshairs and activate by
pressing the joystick.
2. Move crosshairs by moving the
joystick.
> To exit: Press joystick again and
activate Quit moving in the context
menu.
Hide crosshairs.
> Double-touch the crosshairs and
touch Hide in the context menu.
Joystick operation:
1. Select crosshairs and press joystick
twice.
2. In the context menu, activate Hide.
Min/max/avg on area
An area mark can be shown and freely positioned. The minimum
(min), maximum (max) and average (avg) measurement value in
this area is displayed.
Task Actions/description
Show area mark.
> | .
or
>
| | Measurement |
Min/Max on Area.
