8 Analysis & reports
25
7 Dashboard
The dashboard is the home page. It provides an overview of the
key system data: Measuring points and Active alarms.
7.1 Measuring points
A summary of all measuring points is displayed.
Click on the icon to display more information.
7.2 Active alarms
A summary of all active alarms and system warnings is displayed.
Unread alarms and system warnings are shown in bold.
Click on the icon to display more information.
On displaying the detailed information, the alarm
message/system warning is marked as "read" and the alarm
counter is marked down.
8 Analysis & reports
8.1 Data analysis
Displaying and analyzing readings and alarms
The display can be filtered according to the following
characteristics:
• By measuring point group/measuring point: click on the
checkbox in front of the measuring point group/measuring
point.
• By date/time: click on the start date/end date and select the
start date/start time and end date/end time.
• By time range: click on the required time range, for
example Last hour.
Readings can be displayed in a table or as a graphic.
• Click on the Table or Graphic button to select the required
view.
• In the Graphic data view, other analysis functions are
available. See Online Help.
Alarms can be presented as a table.
• Click on the Alarms button to display the alarms.
• Click on the icon to display more information.
