4 Product description
27
Pos: 40 /TD/Produk tbeschreibung/ Übersicht/testo Saver is/04 Converter/ 01 Converter @ 1\mod_119755708 6312_79.docx @ 6416 @ 2 @ 1
4.6. Saveris converter
Antenna for receiving the measurement data.
LED for status display.
Connect button for connecting the converter to the Saveris base
and for a status request during operation.
Catch for the wall bracket.
Guide rails for the wall bracket.
Input for external 24 V AC/DC power supply.
M1.6 x 1.5 cable coupling
Input for connecting the network cable (optional power supply
via PoE).
Input for service interface.
Input for power supply via mains unit.
