Teuco 220M - Page 2

Net
Weight
Kg.
209 300 300 344 1/2"
Ø40
mm
Water
Content
(1)
Kg.
Floor
Load
Kg/m
2
ART. 220 S - 220 E
Delivery
Weight
Kg.
5,68
Delivery
Volume
m
3
TOP 8
Vers.
No. Jets
Water
Capacity
400
l/min.
280
l/min.
Air
Capacity
69 ÷16
2 ÷ 5
bar
Capacity
l/min
Min.Max.
Pressure
Supply
Drain
Conn.
HYDRAULIC CHARACTERISTICS
Hydromassage Multifunctions
2
1
Vert.
Jets
Foot
Jets
Cent.
Sh.He.
620
1100
80
1330
350
1100
1425
1160
750
1100
1200
2000
2000
2315
C - Hot water connection for
1
/2
"
tap fittings
F - Cold water connection for tap fittings and sauna
1
/2
"
O - Connection for drainage pipe recessed in floor
Ø40mm
CA - Electrical connection for Hydromassage IPX5
(box with cable press PG 13,5)
CA1 - Electrical connection for sauna and
Multifunctions
IPX5 (box with cable press PG 21)
N.B. Installation must take place once floors and
walls are completed.
The room in wich the sauna is to be installed
should be at least 240 cm high for service and
maintenance purposes.
97
160
Ø 40
Siphon
19
The information and characteristics shown do not bind Teuco Guzzini Spa who reserves the right to make any modifications it retains necessary without any prior warning or notice of replacement.
Measurements in mm.
Electric connections must be effected in accordance with safety regulations for bathroom installation as
described in the enclosed instruction booklet.
Kw
Min. Max
Art.
5NTX18
5MTX18
2,4÷5
2,4÷5
-
0,05
Art.
2WTX28
Kw
1,35
Kw
ELECTRICAL
CHARACTERISTICS
(2)
Sauna Multifunctions Whirlpool
(1) - Overflow level. (2) - Before connecting the appliance, make sure that the voltage indicated on the rating plate is the same as that of the electric mains
PRE-INSTALLATION CARD ART. 220S-220E
(mm 1330 x 1330)
GB
