Teuco 220M - Page 5

22
ASSEMBLING THE CABIN
GB
5
APPLYING SILICONE
Apply a NEUTRAL (NON ACETIC)
silicone so as to prevent water from
leaking between the back panel
and the bathtub.
A1 B1
4,2x45
Ø5
C1
C1
INSTALLING THE TOP
TRACK
Remove the screws (C1) from the
ends of the top track.
Insert the track onto the ends of
the supports and fasten it to the
back panels using the screws and
washers (C1) that were removed
earlier.
Tighten the screws on the ends of
the side panel supports (A1) and
(B1).
4
