Model Number: 40699 9
Connecting your DVD Player
Front Panel
1. DVD DOOR 5. REMOTE RECEIVER WINDOW
2. OPEN/CLOSE BUTTON 6. DISPLAY WINDOW
3. STOP BUTTON 7. USB JACK
4. PLAY/PAUSE BUTTON 8. POWER BUTTON
Rear Panel
1. Y Pb/Cb Pr/Cr component output jack 4.2CH Right output jack
2. Video output jack 5. Digital Signal Coaxial out jack
3.2 CH Left output jack 6.S-Video output jack
7. Digital Signal Optical output jack
