LAUNCHXL-F28027 Hardware www.ti.com
4.6 Device Migration Path
Applications developed on the LAUNCHXL-F28027 can easily be migrated to any of these lower cost
devices in the F2802x family:
Part Number Description
TMS320F28027
(1)
32-bit Real Time Microcontroller, 60 MHz, 32K Flash, 6K RAM, 4 HRPWM
TMS320F28026 32-bit Real Time Microcontroller, 60 MHz, 16K Flash, 6K RAM, 4 HRPWM
TMS320F28023 32-bit Real Time Microcontroller, 50 MHz, 32K Flash, 6K RAM, 4 HRPWM
TMS320F28022 32-bit Real Time Microcontroller, 50 MHz, 16K Flash, 6K RAM, 4 HRPWM
TMS320F28021 32-bit Real Time Microcontroller, 40 MHz, 32K Flash, 5K RAM
TMS320F28020 32-bit Real Time Microcontroller, 40 MHz, 16K Flash, 3K RAM
TMS320F280200 32-bit Real Time Microcontroller, 40 MHz, 8K Flash, 3K RAM
(1)
This device is present on the LAUNCHXL-F28027.
5 LAUNCHXL-F28027 Hardware
5.1 Device Pin Out
Table 1 lists the pin out and pin mux options for the C2000 LaunchPad.
Table 1. C2000 LaunchPad Pin Out and Pin Mux Options
Mux Value Mux Value
3 2 1 0 J1 Pin J5 Pin 0 1 2 3
+3.3V 1 1 +5V
ADCINA6 2 2 GND
TZ2 SDAA SCIRXDA GPIO28 3 3 ADCINA7
TZ3 SCLA SCITXDA GPIO29 4 4 ADCINA3
Rsvd Rsvd COMP2OUT GPIO34 5 5 ADCINA1
ADCINA4 6 6 ADCINA0
SCITXDA SPICLK GPIO18 7 7 ADCINB1
ADCINA2 8 8 ADCINB3
ADCINB2 9 9 ADCINB7
ADCINB4 10 10 NC
3 2 1 0 J6 Pin J2 Pin 0 1 2 3
Rsvd Rsvd EPWM1A GPIO0 1 1 GND
COMP1OUT Rsvd EPWM1B GPIO1 2 2 GPIO19 SPISTEA SCIRXDA ECAP1
Rsvd Rsvd EPWM2A GPIO2 3 3 GPIO12 TZ1 SCITXDA Rsvd
COMP2OUT Rsvd EPWM2B GPIO3 4 4 NC
Rsvd Rsvd EPWM3A GPIO4 5 5 RESET#
ECAP1 Rsvd EPWM3B GPIO5 6 6 GPIO16/32 SPISIMOA/ Rsvd/ TZ2/
SDAA EPWMSYNCI ADCSOCA
TZ2/ Rsvd/ SPISIMOA/ GPIO16/32 7 7 GPIO17/33 SPISOMIA/ Rsvd/ TZ3/
ADCSOCA EPWMSYNCI SDAA SCLA EPWMSYNCO ADCSOCB
TZ3/ Rsvd/ SPISOMIA/ GPIO17/33 8 8 GPIO6 EPWM4A EPWMSYNCI EPWMSYNCO
ADCSOCB EPWMSYNCO SCLA
NC 9 9 GPIO7 EPWM4B SCIRXDA Rsvd
NC 10 10 ADCINB6
8
LAUNCHXL-F28027 C2000 Piccolo LaunchPad Experimenter Kit SPRUHH2A–July 2012–Revised January 2014
Submit Documentation Feedback
Copyright © 2012–2014, Texas Instruments Incorporated
