MSP430F23x
MSP430F24x(1)
MSP430F2410
SLAS547I –JUNE 2007–REVISED DECEMBER 2012
www.ti.com
Table 20. Port P1.0 to P1.7 Pin Functions
CONTROL BITS / SIGNALS
PIN NAME (P1.x) x FUNCTION
P1DIR.x P1SEL.x
P1.0 (I/O) I: 0; O: 1 0
P1.0/TACLK 0 Timer_A3.TACLK 0 1
CAOUT 1 1
P1.1 (I/O) I: 0; O: 1 0
P1.1/TA0 1 Timer_A3.CCI0A 0 1
Timer_A3.TA0 1 1
P1.2 (I/O) I: 0; O: 1 0
P1.2/TA1 2 Timer_A3.CCI1A 0 1
Timer_A3.TA1 1 1
P1.3 (I/O) I: 0; O: 1 0
P1.3/TA2 3 Timer_A3.CCI2A 0 1
Timer_A3.TA2 1 1
P1.4 (I/O) I: 0; O: 1 0
P1.4/SMCLK 4
SMCLK 1 1
P1.5 (I/O) I: 0; O: 1 0
P1.5/TA0 5
Timer_A3.TA0 1 1
P1.6 (I/O) I: 0; O: 1 0
P1.6/TA1 6
Timer_A3.TA1 1 1
P1.7 (I/O) I: 0; O: 1 0
P1.7/TA2 7
Timer_A3.TA2 1 1
68 Submit Documentation Feedback Copyright © 2007–2012, Texas Instruments Incorporated
